EduBlue Stereo Binocular Microscope, 10x/20x/40x, Rack and Pinion Stand, 1W LED Ilumination

The EduBlue stereo microscopes from Euromex in the Netherlands are designed for education offering excellent optical and ergonomic performance to satisfy long working sessions for students of beginner or advanced life science classes. The two parallel optical paths allow three dimensional inspection of small objects such as insects, plants, stones and minerals.

The EduBlue range is available with dual or triple objectives for 5x to 80x magnification and a choice of rack & pinion or pillar stands. Digital models are also available equipped with a 3.2 MP camera. This model, EduBlue ED.1802-S, is configured with a rack and pinion stand and triple revolving objectives providing total magnification of 10x, 20x, and 40x. The magnification can be altered by using optional eyepieces. All lenses are anti-fungus treated and anti-reflection coated to maximise light throughput.

Illumination is provided by two sets of 1W LED in both incident and transmitted sub-stage configuration. Both illuminations can be used together and the light intensity can be adjusted separately. Supplied with an external 100-240 V mains adapter/charger and 3 rechargeable batteries for corded or coreless use.

View alternative models of EduBlue on the Similar Products Tab.

Features include:

* Binocular head with 45 included tubes
* WF 10x/20 mm eyepieces
* One eyepiece with +/- 5 dioptre adjustment
* Interpupillary distance adjustable from 55 mm to 75 mm
* Triple revolving objectives 1x, 2x, & 4x
* Total magnification 10x, 20x & 40x
* Field of View 20, 10 and 5 mm respectively
* Working distance 60 mm
* Maximum object height 36 mm
* Ergonomic Rack & pinion stand with carrying grip
* 2 object clamps
* 60mm transparent and black/white stage plates
* 1W LED illumination in both incident and transmitted, dimmable
* 5 Year warranty (2 years for electrical parts)
* Dimensions in mm: 260 (h) x 175 (w) x 220 (d)
* Weight 2.1kg

Box contains:-
Microscope, power cord, dust cover, eyecups and user manual. All packed in styrofoam case.


Euromex offer a range of accessories including digital cameras, eyepieces, objectives and lighting. We have selected some of the more popular optional items for this microscope which can be found on the Related Accessories tab.

More Information
Brand Euromex
Product List Attributes

* Fixed 10x/20x/40x magnification
* Ergonomic Rack & Pinion stand, 60mm WD
* Double 1W LED illumination
* Corded or Cordless use

SKU ED.1802-S
Country of Origin China
Used By Schools, Hobbyist
Objective Lens N/A
Measurement No
Magnification Type Triple Power
Magnification 10x/20x/40x
Working Distance 60 mm
Illumination Type 1W LED
Head Type Binocular
Stand Type Rack & Pinion
Special Feature Cordless use, APL
