Package Includes:
This package combines the top-of-the-line EVO optical head mounted on a robust boom stand with the an Auto-focus 60 FPS HDMI Camera and Polarised LED Ring light. The EVO Optics have extra wide field of view eyepieces and a long working distance of 110mm.
The Auto-Focus HDMI Camera connects directly to any HD monitor and streams live video at 60 FPS to create a superb digital inspection with almost no image latency. Save images and videos to SD Card or wirelessly to a computer.
This NexiusZoom EVO stereo microscope is ideally suited for inspection of all kinds of material surfaces in industry and laboratories. Used by electronic and mechanical engineers, lab technicians, gemologists and discerning hobbyists.
Microscope Features
The optical system of NexiusZoom EVO is based upon the Greenough principle with a large 1:8.4 zoom objective providing magnification from 6.5x to 55x with the standard objective and up to 220x with auxiliary lenses and eyepieces. The result is a large working distance of 110mm and field of view from 33m to 4.9mm. All lenses are anti-fungus treated and anti-reflection coated to maximise light throughput.
| Head | Trinocular head with 45° included tubes |
| Eyepieces | Two HWF 10x/23 mm eyepieces |
| Dioptre Adjustment | Both eyepieces with +/- 5 dioptre adjustment |
| Interpupillary distance | 55 mm to 75 mm adjustable |
| Objective | 1:8.4 Zoom, 0.65x to 5.5x magnification, with click stop |
| Magnification* | 6.5x to 55x |
| Field of View* | 33 mm to 4.9 mm |
| Working Distance* | 110 mm |
| Magnification range with included accessory lenses | 3.25x to 55x |
| Accessory lenses included | 0.5x |
| Accessory lenses optional | 0.75x 1.5x and 2.0x |
| Weight | 18kg |
| Warranty | 10 years (2 years for electrical parts) |
* with standard 1x lens and 10x eyepiece
Optical Data
| Objective Lens | 1x (Std) | 0.5x | 0.75x | 1.5x | 2.0x |
| Magnification zoom range | 6.5 to 55x | 3.25x to 27.5x | 4.9x to 41.3x | 9.8x to 82.5x | 13.0x to 110x |
| Working distance | 110 mm | 183 mm | 120 mm | 53 mm | 34 mm |
| Field of View at min. zoom | 35.4 mm | 70.8 mm | 47.2 mm | 23.6 mm | 17.7 mm |
| Field of View at max. zoom | 4.2 mm | 8.4 mm | 5.6 mm | 2.8 mm | 2.1 mm |
Camera Specification
The Euromex HD auto-focus HDMI microscope camera, model VC.3034, is a new solution to modern microscopy for industry and education where real time images are needed directly on a TV, Monitor or projector. This camera has auto focus making it ideal for industrial inspection and quality control.
The camera can be used in two modes, in a stand-alone with its embedded mouse-driven software or in a computer controlled mode. No PC is required to operate in stand-alone mode. Image Focus Alpha software is provided for connection when required to a computer by WiFi (Windows & Mac OS).
The software offers extensive on screen features including measurement functions with calibration, digital zoom, camera settings, image comparison and more.
To connect the camera to the NexiusZoom a high quality photo-port adapter is included, model NZ.9850. Photo port adapters work in a similar way to c-mount adapters but are shorter in design, include a focusing ring and are of higher quality optics, resulting in improved imaging.
Available with 13" HD Monitor (VC.3034-HDS) or as camera only (VC.3034) to connect to your own HD monitor.
| Product Code | VC.3034 or VC.3034-HDS with 13" Monitor |
| Model | HD Auto-Focus |
| Pixels | 2.0 |
| Sensor Size (inch) | 1/1.9" |
| Pixel Size (µm) | 3.75 x 3.75 |
| Resolution | 1920 x 1080 (Live view & capture) |
| Max. frames per sec | 60 fps |
| Interface | HDMI / WiFi |
| Software | Embedded (no computer required) & Image Focus Alpha for Windows/Mac |
| Warranty | 2 Years |
Illumination
A Polarising LED ring light is provided for demanding applications and reduce unwanted glare and reflections. The 16 super high power LEDs integrated into the polarisation ring light provide a remarkable level of brightness. This advanced lighting system ensures your specimens are perfectly illuminated. For crystal-clear imaging and explore the intricate details with unparalleled precision. Long life span and low energy consumption. Light intensity is adjustable directly on the ring light. Removable polarizer/analyzer.
Package Contains
- NZ.1703-B Microscope, power cord, dust cover, spare fuse and user manual.
- VC.3034 HD Auto-focus Camera, HDMI cable, 12vdc/1A power supply, 32GB SD Card and USB mouse, 0.5x C-Mount objective, 30.0 and 30.5 mm adapters, 72 x 24 mm Calibration Slide (1mm/100 - 10micron division) + Optional 13" HD Monitor
- NZ.9850 0.5x Photo-port adapter
- LE.1975 - LED Ring Light & power supply
- NZ.8905 Accessory Lens 0.5x
A range of accessories are available for this package including eyepieces, objectives and lighting. We have selected some of the more popular optional items for this microscope which can be found on the Related Accessories below.
| Brand | Euromex |
|---|---|
| Product List Attributes | • 3.25x to 55x Magnification |
| SKU | NZ-EVO-Promo-4 |
| Country of Origin | China |
| Badges | Bundle |
| Tariff Code | 90111090 |
| Used By | Industry, Laboratories, University |
| Measurement | Yes |
| Magnification Type | Zoom |
| Magnification | 6.5x-55x |
| Working Distance | 110 mm |
| Illumination Type | LED Ring Light |
| Head Type | Trinocular |
| Stand Type | Boom Arm |
| Resolution | HD 1080p |
| Special Feature | Auto-Focus, Wireless Ready, Polariser, Integrated Camera, Integrated Monitor, 3D Inspection, APL |
