This package combines the popular StereoBlue Stereo Microscope from Euromex in Netherlands mounted on a flexible pillar stand with the latest HDMI Camera. The parfocal zoom objective provides variable magnification between 7.5x and 45x. The magnification can be further altered by using optional eyepieces and auxilliary lenses. Working distance with standard lens is 100mm.

Illumination is provided by two sets of 3W LED in both incident and transmitted sub-stage configuration. Both illuminations can be used together or separately and the light intensity can be adjusted separately.

The HDMI Camera connects directly to any HD monitor to create an superb digital inspection and measurement system where you can switch between using eyepieces and a monitor. Save images and videos to SD Card.

StereoBlue stereo microscopes from Euromex in the Netherlands are designed for professional use in laboratories, industry and education offering excellent optical performance and robust construction

Microscope Features

The optical system of StereoBlue is based upon the Greenough principle with a large 1:6.4 zoom objective providing magnification from 7.0x to 45x with the standard objective and up to 135x with auxiliary lenses and eyepieces. The result is a large working distance of 100mm and field of view from 30m to 4.6mm. All lenses are anti-fungus treated and anti-reflection coated to maximise light throughput.

Head Trinocular head with 45° included tubes
Eyepieces Two HWF 10x/20 mm eyepieces
Dioptre Adjustment Both eyepieces with +/- 5 dioptre adjustment
Interpupillary distance 55 mm to 75 mm adjustable
Objective 1:6.4 Zoom, 0.7x to 4.5x magnification, with click stop
Magnification* 7.0x to 45x
Field of View* 30 mm to 4.6 mm
Working Distance* 100 mm
Accessory lenses optional 0.5x, 0.75x and 1.5x
Weight 8kg
Warranty 10 years (2 years for electrical parts)

* with standard 1x lens and 10x eyepiece

Optical Data

Objective Lens 1x (Std) 0.5x 0.75x 1.5x
Magnification zoom range 7 to 45x 3.5x to 22.5x 5.3x to 33.8x  10.5x to 67.5x
Working distance 100 mm 170 mm 114 mm 48 mm
Field of View at min. zoom 30 mm 59.9 mm 40.0 mm 19.9 mm
Field of View at max. zoom 4.6 mm 9.3 mm 6.2 mm 3.1 mm

Camera Specification

The HD Mini camera connects direct to any HD monitor using the supplied HDMI cable to create an excellent stand-alone compound microscope where you can switch between using eyepieces and a monitor. On-board software and integrated SD card means no computer is required to save images and videos.

The software offers extensive on screen features including measurement functions with calibration, digital zoom, camera settings, image comparison and more.

Available with 11.6" HD Monitor (VC.3024-HDS) or as camera only (VC.3023) to connect to your own HD monitor.

Product Code VC.3023 or VC.3024-HDS with 11.6" Monitor
Model HD Mini
Pixels 2.0
Sensor Size (inch) 1/2.8"
Pixel Size (µm) 2.9 x 2.9
Resolution 1920 x 1080 (Live view & capture)
Max. frames per sec 60
Interface HDMI
Software Embedded (no computer required)
Warranty 2 Years

Package Contains

  • SB.1903-P Microscope, power cord, dust cover, spare fuse and user manual.
  • Camera, HDMI 2.0 Cable, 12vDC/1A Power Supply, 16GB SD Card and USB Mouse, 0.5x C-Mount Adapter, 30.0 and 30.5 mm adapters

A range of accessories are available for this package including eyepieces, objectives and lighting. We have selected some of the more popular optional items for this microscope which can be found on the Related Accessories below.

More Information
Brand Euromex
Product List Attributes

• 7x to 45x Magnification
• Trinocular Head with 10x/20mm eyepieces
• HDMI Camera, No PC required
• Pillar Stand, WD 100mm
• Double 3W LED illumination

SKU SB-Pillar-Promo
Country of Origin China
Used By Industry, Laboratories, University, Hobbyist
Measurement Yes
Magnification Type Zoom
Magnification 7x-45x
Working Distance 100 mm
Head Type Trinocular
Stand Type Pillar
Resolution 2.0 Megapixel
Special Feature Integrated Camera
