The VC.3034 HD Auto-Focus Microscope Camera from Euromex is the perfect solution where real time images are needed for inspection, education and live demonstrations. Connect it directly to a monitor, TV or projector using the HDMI interface for fast frame speeds up to 60 fps, or use WiFi to connect to a computer. The VC.3034 camera is equipped with a Full HD 1080p CMOS sensor from Sony providing 24 bit colour rendering and superb image quality. For use with stereo, biological and metallurgical microscopes

AutoFocus feature - move your object under a microscope equipped the VC.3034 and it automatically refocuses when changing subjects or according to changes in topography- no more re-focusing!

Stand-alone Operation: connect directly to a monitor or projector using HDMI output at full 60 fps (frames per second). No computer is needed. The embedded mouse-driven software enables image capture and saving videos to an SD memory card all with no computer. The software also offers extensive on screen features including measurement functions with calibration, digital zoom, camera settings, image comparison and more. Stand-alone model is ideal for inspection tasks or sharing images on a large monitor where real time images are needed.

Available with 13" HD Monitor (VC.3034-HDS) or as camera only (VC.3034) to connect to your own HD monitor.

Computer Controlled Mode: for more control and software functions the VC.3034 camera is provided with a WiFi dongle to connect a computer (ImageFocus Alpha software), should you wish to do so. More camera and image controls, calibrated measurements on live and still images and the ability to create annotations on captured images. Compatible with Windows 7, 8 and 10, both 32 and 64 bits. A version for Mac OS is also available with some differences in features.

Microscope connection: the HD Autofocus connects to microscopes fitted with a standard 23.2 mm tube using a 0.5x C-Mount (included). Conversion adapters, 30.0 and 30.5 mm, are included for use with stereo microscopes. Adaters for most other microscope brands are also available, please contact us.

Features include:

* Fits C-Mount or eyepiece with 30.0 & 30.5 adapters included
* 1920 x 1080 pixels (live view)
* Auto-Focus feature
* Stunning image quality
* HDMI & USB-C interface
* Sony CMOS Sensor 1/1.9"
* HDMI 60 fps
* Image Capture to SD Card
* Measurement & calibration capability
* 1 Year warranty
* Dimensions: 80 x 65 x 80 mm
* Weight: 500gm

Box contains:-

HD-Autofocus Camera, HDMI cable, 12vdc/1A power supply, 16GB SD Card and USB mouse, 0.5x C-Mount objective, 30.0 and 30.5 mm adapters, 72 x 24 mm Calibration Slide (1mm/100 - 10micron division)

About Microscope Cameras

Turn your conventional microscope into a digital microscope. Microscope cameras provide a cost effective solution to viewing and capturing digital images through a traditional microscope and are used in a variety of imaging applications such as microscopy, quality control and automation. You can easily replace the ocular (eyepiece) of your non-digital microscope with one of our microscope cameras and connect it to your computer.

More Information
Brand Euromex
Product List Attributes

• HD1080p Auo-focus, 60fps (2.0MP Sensor)
• HDMI, WiFi and SD Memory card
• C-Mount interface to any microscope
• Measure & save images. No PC required
• Supplied with or without 13" HD Monitor

SKU VC.3034-C
Tariff Code 85258019
Used By Industry, Laboratories, University
Measurement Yes
Sensor Type CMOS
Sensor Format 1/1.9"
Resolution 2.0 Megapixel
Pixel Size (Micron) 3.75 x 3.75
Magnification N/A
Lense Mount C-Mount
Interface type HMDI (DVI)
Frame Rate (Max) 60 fps
Operating System MacOS 10.4 and up, Windows 7, 8, 10 & 11
