The Nikon SMZ745 and SMZ745T stereo microscopes are designed for precision and durability, making them ideal for industrial inspection, materials research, and production-line applications. Featuring a large 7.5:1 zoom ratio and an impressive 115mm working distance, these microscopes offer exceptional versatility for examining components, detecting surface defects, and conducting failure analysis. The SMZ745T model includes a trinocular head with a built-in camera port for seamless digital imaging integration.
Built with Nikon’s Greenough optical system, the SMZ745 series delivers magnification from 3.35x to 300x when paired with auxiliary eyepieces and objectives. Both models are engineered for demanding environments, with air-tight body joints to prevent contamination, electrostatic discharge (ESD) coatings for anti-static protection, and anti-mould treatments for high-humidity conditions. These features ensure reliable performance across a wide range of industrial settings.
Whether you're inspecting aerospace components, textiles, or machined parts, the SMZ745 series provides the clarity, flexibility, and ruggedness needed for critical visual assessments. Its compact design and high-quality optics make it a trusted choice for professionals seeking dependable stereo microscopy solutions.
Microscope Features
| Head | Binocular or Trinocular head with 45° included tubes |
| Camera Adapter (Trinocular head only) | Built-in C-mount 0.55x magnification lens for2/3 inch or smaller sensor |
| Eyepieces | Two 10x/25 mm eyepieces, FN 22 |
| Dioptre Adjustment | Both eyepieces with +/- 5 dioptre adjustment |
| Interpupillary distance | 52 mm to 75 mm adjustable |
| Objective | 7.5:1 Zoom, 0.67x to 50x magnification, with click stop |
| Magnification* | 6.7x to 50x |
| Working Distance* | 115 mm |
| Magnification with optional accessory lenses | 3.35x to 300x |
| Accessory lenses optional | 0.5x, 0.7x, 1.5x AND 2.0x |
| Accessory eyepieces optional | 15x, 20x and 30x |
| Weight | 8kg |
| Warranty | 1 year |
* with standard 1x lens and 10x eyepiece
Optical Data
| Objective Lens | 1x (Std) | 0.5x | 0.7x | 1.5x | 2.0x |
| Magnification zoom range | 6.7x to 50x | 3.5x to 25x | 4.7x to 35x | 10x to 75x | 13.4x to 100x |
| Working distance | 115 mm | 211 mm | 150 mm | 61 mm | 43.5 mm |
Camera (Optional)
Nikon Digital Sight 1000 Microscope Camera
The Digital Sight 1000 is a colour camera that can directly display high-definition microscope images on a full HD display without the need for a PC. Digital Sight 1000 can also be connected to a tablet PC to save space and simplify operation.
Equipped with a 2 megapixel CMOS image sensor, the Digital Sight 1000 can display, capture and save full HD, 1920 x 1080 pixel images at 30 frames / second.
Stand-alone Mode
By connecting a Full HD display and a mouse, the Digital Sight 1000 can be used without a PC, conserving bench space. Captured images and videos can be saved directly to an SD card which is inserted into the camera. Users can easily display scale bars, measure areas and calculate distances between two points.
Package Contains
- SMZ745/T Microscope, Hybrid C-LEDs stand, 2 x C-10X Eyepieces, power cord, dust cover and user manual
- Optional DS1000 Camera, HDMI 2.0 Cable, 12vDC/1A Power Supply and USB Mouse
A range of accessories are available for this package including eyepieces, objectives and lighting. We have selected some of the more popular optional items for this microscope which can be found on the Related Accessories below.
| Brand | Nikon |
|---|---|
| Product List Attributes | • Greenough Zoom 7.5 : 1 |
| SKU | SMZ745 |
| MPN | SMZ745 |
| Country of Origin | Japan |
| Badges | New |
| Tariff Code | 9011109000 |
| Used By | Industry, University |
| Magnification Type | Zoom |
| Magnification | 6.7x-50x |
| Zoom ratio | 7.5:1 |
| Working Distance | 115 mm |
| Illumination Type | LED |
| Head Type | Binocular |
| Stand Type | Rack & Pinion |
