Vision-Luxo KFM LED Industrial Bench Magnifier, 2x9W, 1143mm Arm, 3.0 or 5.0 Diopter, Grey
- 3.0 or 5 dioptre (1.75x and 2.25x magnification) options
- Choice of secondary lenses to increase magnification to a total of 15 dioptre (4.75x)
- 127 mm crown glass lens for maximum clarity, precision and comfort.
- 1143mm Arm - Self-balancing, flexible 'Move & Stay' with edge clamp or optional weighted based
- Dimmable illumination 1-100%
- Automatic shut-off feature for energy efficiency
- Range of available accessories and mounting options
- Warranty 5 years (1yr on electrical parts)
Optimised for industrial applications, the KFM LED professional bench magnifier is ideal for electronics rework, deburring, sample preparation, dissection, assembly and manipulation.
Shadow-free illumination
KFM LED has 11W LED modules providing 3000 lux at 330mm focal length with 4000k colour temperature. Dimming from 1-100%.
Flexible working positions
Vision-Luxo magnifiers are specially designed to maximize horizontal and vertical movement. The 3 pivot, 1143mm long arms, provide significant horizontal reach and will always stay in the right position without drifting. The arms are balanced by spring systems which ensure smooth and easy positioning – no knobs to tighten, nothing to adjust, just move and it stays.
The flexibility of the self-balancing arm and friction-free joint between the head and arm makes exact positioning easy. The fully-enclosed neck design is ideal for mechanical, electronics, circuit boards, dental and jewellery and other precision applications.
Glass lens for superb clarity and comfort
The quality of KFM LED is ensured with the high performance optical glass lens providing super clarity and low distortion. The 127mm diameter crown glass lens has a lower refractive index than plastic lens magnifiers, which reduces the loss of light in transmission through the lens and therefore less distortion of the image. Result: more comfortable viewing over longer periods of time.
Secondary lense: for additional magnification a secondary 4, 6 or 10 dioptre STAYS lens can be attached to the primary lens.
Optical Data:
Model Nr. | Primary lens dioptre |
Secondary lens dioptre |
Total magnification |
Total dioptre |
Focal length |
KFM026039 | 3.0 | 1.75X | 3 | 330mm (13") | |
3.0 | 4.0 | 2.75X | 7 | 140mm (5.5") | |
3.0 | 6.0 | 3.25X | 9 | 110mm (4.3") | |
3.0 | 10.0 | 4.25X | 13 | 70mm (2.8") | |
KFM026041 | 5.0 | 2.25X | 5 | 200mm (8") | |
5.0 | 4.0 | 3.25X | 9 | 110mm (4.2") | |
5.0 | 6.0 | 3.75X | 11 | 90mm (3.5") | |
5.0 | 10.0 | 4.75X | 15 | 50mm (2") |
Package contains: Magnifier, UK Plug Type G, Edge mounting clamp
For other models of KFM LED - see Related Products tab.
For accessories - see Related Accessories tab.
About Vision & Luxo
Vision Engineering's collaboration with Luxo Corporation, provides a range of illuminated industrial bench magnifiers offering outstanding performance for a range of manufacturing, assembly and inspection tasks.
These quality bench magnifiers provide perfect balance and flexibility for efficient working. With magnification ranging from 1.75x to 4.75x and superb optical quality the range includes EDS / UV variants for specialist industry requirements.
Brand | Vision-Luxo |
---|---|
Product List Attributes | • 3.5 or 5 dioptre (1.88x or 2.25x) |
SKU | KFMLED |
Country of Origin | Norway |
Tariff Code | 90314990 |
Illuminated | Yes |
Lens Type | Glass |
Scale | None |
Used By | Industry, Laboratories |
